古构造残余应力场X射线测量

基金项目: 地震学联合科学基金资助的课题

MEASUREMEAT OF PALEOTECTONIC RESIDUAL STRESS FIELD BY X-RAY DIFFRACTOMETRY

摘要: 以岩体正交各向异性弹性理论为基础,用X射线衍射法,沿红河断裂带布设7条测线,沿迁西山字型构造带布设11条测线,完成了岩体中三维残余应力测量,绘出了宏观残余应力场等值线及主应力线图、微观残余应力场等值线图,算出了岩体内两种残余弹性应变能密度场,确定了其形成时期。
- 残余应力场 /
- 应变能密度场 /
- 三维 /
- 正交各向异性 /
- X射线衍射法
Abstract: This treatise has accomplished residial stresses measurement of three dimensions in rock masses in Honghe fracture zone and Qianxi epsilon-shaped structural system, has drawn isopleth and principal stress line maps of macro——residual stresses as well as isopleth map of micro——residual stresses, has evaluated elastic strain energy density fields of aforesaid two kinds of residual stresses in rock masses in these regions and has determined their formed periods. The measurement has been based on orthotropic elastic theory of rock mass and used the x-ray diffraction method.

[1]	安欧,X射线地应力测量原理和方法,地震研究,2, 3, 1979
[2]	安欧,迁西地区构造体系的x射线鉴定,地质钭学,1,1982.
[3]	Friedman M., Residual elastic strain in rocks, Tectonophy, 15, 1972
[4]	星野一男,安田俊一,小出仁,关东中部地方に於汁る治残留応力の测定例,地质调查所,1978.
[5]	Jaeger C., In-situ residual stresses in rock masses, Rockmech, Eng., Cambridge Univ., Ch.5, 1972.
[6]	Oberti G., Residual stress measarement in rock masses, proc.lst.congr.Int.Soc, Rockmech., 2, 1966.
[7]	Swolfs H.S., et al, Field measurements of residual strain in granitic rock mass, Advances in Rock Mechanics, proc.3rd cong.ISRM I, 1974.
[8]	Holzhausen G.R. The concept of residual stress in rock, Tectonophysics, 58,1979,
[9]	H.Bock, Experimental determination of the residual stress field in a basaltic columa, 4th Intcrnatiolina 1.Congress on Rock Mechanics, 1, 1979.
[10]	T.Engelder, P.Geiser, Resijuac stress in the Tully Limestone Appalaciiaa Plateau, Journal of Geophysical Research, 89, Bll, 1984.
[11]	安欧,绝对弹性地形变的x射线测量与地震,西北地震学报,6, 4, 1984.
[12]	陈宗基和康文发,岩石的封闭应力,蠕变和扩容以及本构方程,第四届国际岩石力学会议论文选集, 冶金工业出版社,田良灿等译,1985.
[13]	J.C.Jaegre, N.G.W.Cook, Fundameatals of Rook Mechanics, London 1979.
